Pathophysiology

Complete AV Dissociation R9

The basic rhythm is AV Nodal/Junctional. An independent, slower atrial rhythm is present. There is no conduction of atrial impulses to the ventricles. Since the ventricular rhythm is regular and of AV nodal origin, it is evident that no atrial impulse has activated the ventricles.

Rhythm Strip
12 Lead EKG
Complete AV Dissociation
